VOKERA
ECLIPSE 226 ESC REV 0 (03/2007) - (Combustion 1)
Appliance Code: 2350623

Appliance Diagram


Combustion 1 diagram for Vokera Eclipse 226 ESC Rev 0 (03/2007)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 9806, Auto Air Vent AUTO AIR VENT
Vokera part no. 9806
£11.67
3   EXTENSION FOR AAV'S (4254 + 9806)
Vokera part no. 8911
£4.78
4   COMBUSTION CHAMBER TOP
Vokera part no. 8881

5 Part number 8675, Flue Clamp and Gasket FLUE CLAMP AND GASKET
Vokera part no. 8675
£6.32
6   OBSOLETE SEAL FOR MAINTENANCE CLIP (LARGE)
Vokera part no. 5920

7 Part number 8084, Air Box Hole Cap AIR BOX HOLE CAP
Vokera part no. 8084
£4.08
8   WASHER
Vokera part no. 8975
£2.82
9 Part number 5905, Combustion Chamber seal (1 metre) COMBUSTION CHAMBER SEAL (1 METRE)
Vokera part no. 5905
£2.37
10   ANALYSER TEST POINT TUBE
Vokera part no. 8908

11   WASHER
Vokera part no. 8912
£5.30
12   ECLIPSE HEAT EXCHANGER OVERHAUL KIT
Vokera part no. 8884

13   WASHER
Vokera part no. 9287
£8.24
14 Part number 1193, Front Insulation Panel FRONT INSULATION PANEL
Vokera part no. 1193
£25.20
15 Part number 1033, Cover for condensing assembly COVER FOR CONDENSING ASSEMBLY
Vokera part no. 1033

16   INSULATION PANEL
Vokera part no. 1016
£3.45
17   ROOM SEALED CHAMBER
Vokera part no. 10022672
£69.35
19   GLASS KIT
Vokera part no. 01005234
£7.76
23 Part number 01005242, Spark Electrode Kit SPARK ELECTRODE KIT
Vokera part no. 01005242
£51.56
25 Part number 1044, Electrode ELECTRODE
Vokera part no. 1044
£19.99
26   FRONT PANEL FOR AIR BOX
Vokera part no. 1035
£47.68
27 Part number 8909, Plug PLUG
Vokera part no. 8909
£3.41
33   WASHER RING
Vokera part no. 1022

38   CLIP (PACK OF 10)
Vokera part no. 10021115

100   WIRING HARNESS
Vokera part no. 10022355
