VOKERA
EVOLVE 30S REV 4 (03/2019) - (Wiring)
Appliance Code: 41-364-01 REV 4

Appliance Diagram


Wiring diagram for Vokera Evolve 30S Rev 4 (03/2019)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   POWER WIRING HARNESS
Vokera part no. 20132111
£89.50
2   IGNITION CABLE
Vokera part no. 20132114
£59.66
3   COMBUSTION CABLE
Vokera part no. 20154616
£30.31
4   LOW TENSION CABLE
Vokera part no. 20130428
£44.74
5   PUMP CABLE (PWM)
Vokera part no. 20132112
£44.74
6   EXTERNAL UTILITIES CABLE
Vokera part no. 20135598
£30.24
7   D-SUB 25 WAY CONNECTION WIRING
Vokera part no. 20163798
£26.06
8   WIRING HARNESS
Vokera part no. 20124832
£20.48
