VOKERA
MYNUTE 20 VHE,
MYNUTE 20 VHE REV 14 (05/2016),
MYNUTE 20 VHE REV 15 (02/2017),
MYNUTE 20 VHE REVISION 0 (06/2018) - (Hydraulics 2)
Appliance Code: 41-094-70

Appliance Diagram


Hydraulics 2 diagram for Vokera Mynute 20 VHEClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

7 Part number 10026267, Pipe (Rep 10027317) PIPE (REP 10027317)
Vokera part no. 10026267
£28.75
9 Part number 10029515, NOW USE 20020182 Pipe NOW USE 20020182 PIPE
Vokera part no. 10029515

9 Part number 20020182, Flow Pipe Assembly (Rep 10029515) FLOW PIPE ASSEMBLY (REP 10029515)
Vokera part no. 20020182
£74.22
17 Part number 10029306, Auto air vent (Brass) Replaced 100618 AUTO AIR VENT (BRASS) REPLACED 100618
Vokera part no. 10029306
£19.88
25 Part number 10028405, Siphon SIPHON
Vokera part no. 10028405
£53.85
26 Part number 10028540, Condensing pipe CONDENSING PIPE
Vokera part no. 10028540
£5.31
27 Part number 10027192, Flexible pipe FLEXIBLE PIPE
Vokera part no. 10027192
£6.85
71   AIR BLEEDING CONNECTION PIPE
Vokera part no. 10028430
£11.67
72 Part number 01005137, Venting Plugs Kit VENTING PLUGS KIT
Vokera part no. 01005137
£9.76
73 Part number 10028431, COCK (up to serial no, 20099226O0950120) COCK (UP TO SERIAL NO, 20099226O0950120)
Vokera part no. 10028431
£9.55
247 Part number 5203, Plastic Washer PLASTIC WASHER
Vokera part no. 5203
£0.21
476 Part number 10026324, O ring O RING
Vokera part no. 10026324
£2.85
512 Part number 10027193, Washer WASHER
Vokera part no. 10027193
£1.11
574 Part number 10028539, Condensing pipe CONDENSING PIPE
Vokera part no. 10028539
£11.15
581 Part number 10029715, NOW USE 20081926 NTC sensor NOW USE 20081926 NTC SENSOR
Vokera part no. 10029715

581 Part number 20081926, Thermistor/NTC Replaced 20003819 and 20004365 THERMISTOR/NTC REPLACED 20003819 AND 20004365
Vokera part no. 20081926
£16.76
582 Part number 9695, Thermostat THERMOSTAT
Vokera part no. 9695
£8.00
