VOKERA
VISION PLUS 40C REV 3 (11/2021) - (Hydraulics 2)
Appliance Code: 47-364-55 REV 3

Appliance Diagram


Hydraulics 2 diagram for Vokera Vision Plus 40c Rev 3 (11/2021)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

40   SIDE PANEL (LEFT OR RIGHT)
Vokera part no. 20135296
£54.40
50   9LT EXPANSION VESSEL
Vokera part no. 20135958
£122.83
70 Part number 10028421, Flue drain connection Replaced 10026311 FLUE DRAIN CONNECTION REPLACED 10026311
Vokera part no. 10028421
£9.58
80   FUMES FLANGE KIT (UP TO SERIAL NO. 20127447N3859999)
Vokera part no. 20157135
£14.96
90   CAP SMOKE ANALYSIS
Vokera part no. 20157134
£4.18
110   FLANGE GASKET (FROM SERIAL NO. 20099226O1150289)
Vokera part no. 20157133
£1.73
130 Part number 10026345, Washer WASHER
Vokera part no. 10026345
£7.00
330   CAP SMOKE ANALYSIS
Vokera part no. 20171129
£2.81
