WORCESTER
28I JUNIOR RSF LPG - (Casing)
Appliance Code: 47-311-72

Appliance Diagram


Casing diagram for Worcester 28i Junior RSF LPGClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

Part number 29150110090, NUT M8 FULL HEX M/S ZC PL NUT M8 FULL HEX M/S ZC PL
Worcester part no. 29150110090
£4.08
Part number 87161047420, BOTTOM PANEL BOTTOM PANEL
Worcester part no. 87161047420
£30.22
  COLLECTOR HOOD ASSEMBLY
Worcester part no. 87161056710
£37.74
Part number 87161412110, BLANKING CAP RED BLANKING CAP RED
Worcester part no. 87161412110
£2.63
  GAS SENSOR CONNECTOR
Worcester part no. 87161412270
£4.66
1   MANTLE ASSEMBLY
Worcester part no. 87161056720
£84.73
2   WALL FRAME ASSEMBLY
Worcester part no. 87161056670
£277.52
3 Part number 87161567550, VALVE - C.H. (UK) VALVE - C.H. (UK)
Worcester part no. 87161567550
£16.37
4 Part number 87161563840, CONNECTOR DHW-OUT (UK) CONNECTOR DHW-OUT (UK)
Worcester part no. 87161563840
£8.27
5 Part number 87161567530, GAS COCK (UK) GAS COCK (UK)
Worcester part no. 87161567530
£17.15
6 Part number 87161034240, VALVE - DCW IN (UK) VALVE - DCW IN (UK)
Worcester part no. 87161034240
£29.85
7 Part number 87161034230, VALVE - CH (UK) VALVE - CH (UK)
Worcester part no. 87161034230
£30.80
8 Part number 29144114030, NOW USE 87182242510 SCREW M5X12MM TAPTITE ZC PL P/H (10X) NOW USE 87182242510 SCREW M5X12MM TAPTITE ZC PL P/H (10X)
Worcester part no. 29144114030

8 Part number 87182242510, SCREW M5 X 10MM SCREW M5 X 10MM
Worcester part no. 87182242510
£1.56
9 Part number 87161055450, EXPANSION VESSEL EXPANSION VESSEL
Worcester part no. 87161055450
£88.65
10 Part number 87161424040, PRESSURE RELIEF VALVE 312438 PRESSURE RELIEF VALVE 312438
Worcester part no. 87161424040
£16.89
11 Part number 87186846990, CLIP WIRE 18MM (10X) CLIP WIRE 18MM (10X)
Worcester part no. 87186846990
£2.78
12 Part number 87161081320, MANIFOLD/FLEXIBLE HOSE KIT MANIFOLD/FLEXIBLE HOSE KIT
Worcester part no. 87161081320
£18.50
13 Part number 87161056380, PIPE EXPANSION VESSEL PIPE EXPANSION VESSEL
Worcester part no. 87161056380
£11.55
14 Part number 87167711670, RETAINING SPRING 10MM (10X) RETAINING SPRING 10MM (10X)
Worcester part no. 87167711670
£2.50
15 Part number 87161057920, O RING 7.59 X 2.62 EP70 O RING 7.59 X 2.62 EP70
Worcester part no. 87161057920
£2.95
16 Part number 87161153060, SCREW (10X) 8X1/2" AFTER FD992 SCREW (10X) 8X1/2" AFTER FD992
Worcester part no. 87161153060
£3.59
17 Part number 87161409210, WASHER FIBRE 15.0 X 10.0 X 1.0 WASHER FIBRE 15.0 X 10.0 X 1.0
Worcester part no. 87161409210
£3.20
18 Part number 87161056700, FRONT COVER ASSEMBLY FRONT COVER ASSEMBLY
Worcester part no. 87161056700
£47.36
19 Part number 87161057660, SILICONE SPONGE SILICONE SPONGE
Worcester part no. 87161057660
£3.98
20 Part number 87161057680, SILICONE SPONGE SILICONE SPONGE
Worcester part no. 87161057680
£3.88
21   COMBUSTION COVER
Worcester part no. 87161054370
£18.00
22   INSULATION FRONT
Worcester part no. 87161055360
£10.42
23   INSULATION REAR
Worcester part no. 87161055370
£10.42
24 Part number 87161055400, INSULATION SIDE INSULATION SIDE
Worcester part no. 87161055400
£6.54
25 Part number 87161059370, INSULATION SET INSULATION SET
Worcester part no. 87161059370
£31.01
26 Part number 87161482040, NUT CAPTIVE NO:8 NUT CAPTIVE NO:8
Worcester part no. 87161482040
£4.24
27   RETAINING CLIP
Worcester part no. 87161483630
£1.70
28 Part number 87161057990, FACIA ASSEMBLY 28I JUNIOR FACIA ASSEMBLY 28I JUNIOR
Worcester part no. 87161057990
£5.26
