WORCESTER
80IC FSN GB (NOVATHERM) NG 7713231806 - (Burner)
Appliance Code: 47-311-43

Appliance Diagram


Burner diagram for Worcester 80IC FSN GB (Novatherm) NG 7713231806Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   BURNER ASSEMBLY - NG
Worcester part no. 87081204470
£185.66
2   WASHER (10X)
Worcester part no. 87010030100
£0.72
3   NOZZLE (120) (10X)
Worcester part no. 87082021240
£2.45
4   SCREW M4 X 12 PHILLIPS (10X)
Worcester part no. 29109521220
£0.67
5   SCREW M3,5X10 (10X)
Worcester part no. 87034010690
£0.59
6 Part number 87033051910, PRESSURE TAPPING PRESSURE TAPPING
Worcester part no. 87033051910
£2.45
7   CROSS IGNITION BRIDGE
Worcester part no. 87113043050
£15.42
8 Part number 87101030600, WASHER 1" (10X) WASHER 1" (10X)
Worcester part no. 87101030600
£3.04
9   ANGLE BRACKET
Worcester part no. 87113042870
£5.45
10   SCREW (10X)
Worcester part no. 29106194090
£0.59
12   CONNECTOR
Worcester part no. 87052020920
13   NOW USE 87181070500 IGNITION ELECTRODE
Worcester part no. 87081070080

13 Part number 87181070500, SET OF ELECTRODES SET OF ELECTRODES
Worcester part no. 87181070500
£32.92
14   SCREW M3.5X6 PHILLIPS STEEL (10X)
Worcester part no. 29106420820
£0.59
15   NOW USE 87181070500 SENSING ELECTRODE
Worcester part no. 87081070090

15 Part number 87181070500, SET OF ELECTRODES SET OF ELECTRODES
Worcester part no. 87181070500
£32.92
