WORCESTER
GREENSTAR R25 HE COMBI - (Burner/Heat Exchanger)
Appliance Code: 47-311-77

Appliance Diagram


Burner/Heat Exchanger diagram for Worcester Greenstar R25 HE CombiClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 87154066150, NOW USE 8716119317 HEAT EXCHANGER NOW USE 8716119317 HEAT EXCHANGER
Worcester part no. 87154066150

1 Part number 8716119317, HEAT_EXCHANGER BASIC BLOCK FS/HF HEAT_EXCHANGER BASIC BLOCK FS/HF
Worcester part no. 8716119317
£632.98
2 Part number 87133011140, NUT NUT
Worcester part no. 87133011140
£3.36
3 Part number 87229638580, TEMPERATURE LIMITER BEFORE FD886 TEMPERATURE LIMITER BEFORE FD886
Worcester part no. 87229638580
£30.48
4 Part number 87110002620, COVER COVER
Worcester part no. 87110002620
£66.31
5 Part number 87101031530, SEALING SEALING
Worcester part no. 87101031530
£9.51
6 Part number 87180038360, SHIELD SHIELD
Worcester part no. 87180038360
£5.45
7 Part number 87181070780, NOW USE 8716121817 SET OF ELECTRODES NOW USE 8716121817 SET OF ELECTRODES
Worcester part no. 87181070780

7 Part number 8716121817, SET OF ELECTRODES SET OF ELECTRODES
Worcester part no. 8716121817
£49.58
7 Part number 87186643010, NOW USE 8716121817 SET OF ELECTRODES NOW USE 8716121817 SET OF ELECTRODES
Worcester part no. 87186643010

8 Part number 87145000870, TEMPERATURE SENSOR TEMPERATURE SENSOR
Worcester part no. 87145000870
£27.12
9 Part number 87180066580, BURNER BURNER
Worcester part no. 87180066580
£261.76
10 Part number 87110041680, BURNER SEALING BURNER SEALING
Worcester part no. 87110041680
£18.70
11 Part number 87103052970, FIXING BOLT FIXING BOLT
Worcester part no. 87103052970
£10.85
12 Part number 87154063180, COVER COVER
Worcester part no. 87154063180
£301.72
13 Part number 87290002630, FIXING SET FIXING SET
Worcester part no. 87290002630
£45.80
14 Part number 87290001830, WASHER WASHER
Worcester part no. 87290001830
£8.59
16 Part number 87101001900, CLIP (10X) CLIP (10X)
Worcester part no. 87101001900
£2.84
17 Part number 87110042640, NOW USE 87186644020 GASKET ELECTRODE WASHER NOW USE 87186644020 GASKET ELECTRODE WASHER
Worcester part no. 87110042640

17 Part number 87186643010, NOW USE 8716121817 SET OF ELECTRODES NOW USE 8716121817 SET OF ELECTRODES
Worcester part no. 87186643010

17 Part number 87186644020, WASHER WASHER
Worcester part no. 87186644020
£2.56
18   FLUE GAS COLLECTOR
Worcester part no. 8716119320
£26.20
18 Part number 87180067720, NOW USE 8716119320 FLUE GAS COLLECTOR NOW USE 8716119320 FLUE GAS COLLECTOR
Worcester part no. 87180067720

22 Part number 87105062670, TEMPERATURE LIMITER ASSY AFTER FD887 TEMPERATURE LIMITER ASSY AFTER FD887
Worcester part no. 87105062670
£40.94
