WORCESTER
W275-1KV1B31S0595 (JAN 97 ONWARDS) 7701431795 - (Heating Body)
Appliance Code: 7701431795

Appliance Diagram


Heating Body diagram for Worcester W275-1KV1B31S0595 (Jan 97 Onwards) 7701431795Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   NOW USE 87054063750 HEATING BODY
Worcester part no. 87054061840

1 Part number 87054063750, HEATING BODY HEATING BODY
Worcester part no. 87054063750
£233.33
2   TEMPERATURE LIMITER
Worcester part no. 8738717111
£18.31
2 Part number 87072061320, NOW USE 8738717111 TEMPERATURE LIMIT 110 DEC C. NOW USE 8738717111 TEMPERATURE LIMIT 110 DEC C.
Worcester part no. 87072061320

3   SCREW M4X6MM STEEL PHILLIPS PAN HD
Worcester part no. 29109511160
£0.56
4   CONNECTING PIPE COLD
Worcester part no. 87007056270
£16.24
5   CONNECTION UNION
Worcester part no. 87033010810
£7.97
6   SET OF WASHERS
Worcester part no. 87001036920
£1.32
7 Part number 87002050230, O-RING (10X) O-RING (10X)
Worcester part no. 87002050230
£1.48
8   RETAINING CLIP (10X)
Worcester part no. 87047050250
£0.76
9   DRAIN OFF VALVE
Worcester part no. 87085050040
£44.22
10   WASHER
Worcester part no. 87001030060
£0.74
13 Part number 87101030430, FIBRE WASHER 23.9 X 17.2 X 1.5 FIBRE WASHER 23.9 X 17.2 X 1.5
Worcester part no. 87101030430
£2.70
