POTTERTON COMMERCIAL
NXR3I 4-9 SECTION ISS 03 - (Boiler Body)
Appliance Code: NXR3i

Appliance Diagram


Boiler Body diagram for Potterton Commercial NXR3i 4-9 Section iss 03Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   COMPLETE REAR SECTION
Potterton part no. 8219-8912
£1,835.84
2   INTERMEDIATE SECTION - SPECIAL
Potterton part no. 8219-8966
£827.37
3   FRONT SECTION COMPLETE
Potterton part no. 8219-8976
£1,143.29
4   NIPPLE
Potterton part no. 8116-0571
£11.05
5   COMPLETE ASSEMBLY ROD, 4 SEC
Potterton part no. 8219-8968
£20.25
5   COMPLETE ASSEMBLY ROD, 5 SEC
Potterton part no. 8219-8969
£24.41
5   COMPLETE ASSEMBLY ROD, 6 SEC
Potterton part no. 8219-8970
£20.84
5   COMPLETE ASSEMBLY ROD, 7 SEC
Potterton part no. 8219-8971
£26.72
5   COMPLETE ASSEMBLY ROD, 8 SEC
Potterton part no. 8219-8972
£16.92
5   COMPLETE ASSEMBLY ROD, 8 SEC
Potterton part no. 8219-8972
£16.92
6   PLUG 2 1/2" - 1/2"
Potterton part no. 8013-0028
£26.19
6.3   NIPPLE N 241 - 1/2"X1/4"
Potterton part no. 9494-8080
£5.42
7   RP SENSOR TUBE (1/2)
Potterton part no. 9536-5611
£16.21
7A   SPRING SENSOR TUBE - NXRI RNGE
Potterton part no. 5141640
£1.00
8   PLUG 2 1/2" - 1/2"
Potterton part no. 8013-0028
£26.19
9   FLOW FLANGE + DIST PIPE
Potterton part no. 8553-5513
£115.79
10   RETURN FLANGE (4 & 5 SECTION)
Potterton part no. 8553-5514
£71.61
10A   RETURN FLANGE + DIST PIPE
Potterton part no. 8553-5515
£85.83
10B   RETURN + DIST. PIPE, 9 SECT
Potterton part no. 8553-5516
£112.47
10C   COUNTER FLANGE
Potterton part no. 9754-9178
£37.13
11   MALE PLUG 290 T9 - R 1 1/2
Potterton part no. 9495-0249
£16.47
11A   FLANGE GASKET
Potterton part no. 9501-4122
£9.99
12   HINGE
Potterton part no. 8104-8984
£35.16
13   SWEEPING DOOR
Potterton part no. 8219-8916
£181.98
14   INNER PROTECT
Potterton part no. 9425-0306
£16.28
15   INSULATION - SWEEPING DOOR
Potterton part no. 9425-0305
£35.21
16   SWEEPING DOOR
Potterton part no. 8219-8916
£181.98
17   PIN Ï 12X350
Potterton part no. 9756-0203
£17.92
18   180 COMPLETE NOZZLE
Potterton part no. 8219-8913
£163.32
18   COMPLETE NOZZLE - 200
Potterton part no. 8219-8914
£162.92
19   RIGHT HAND NOZZLE COVER
Potterton part no. 8219-0206
£53.26
20   LEFT HAND NOZZLE COVER
Potterton part no. 8219-0207
£53.19
21   COMBUSTION CHAMBER DOOR P320
Potterton part no. 8219-8953

22   INSULATION -COMB CHAMBER DOOR
Potterton part no. 9425-0303
£12.33
23   FRONT RADIATION QUARL
Potterton part no. 9425-0302
£95.87
24   FURNACE DOOR INSULATION
Potterton part no. 9425-0301
£51.52
25   SIGHT GLASS C/W GASKETS
Potterton part no. 8015-7700
£26.97
26   INSPECTION FLANGE
Potterton part no. 9757-0027
£4.74
27   PLUG 1/4"
Potterton part no. 9495-0050
£5.59
28   GUIDE RAIL - COMB CHAMBER DR
Potterton part no. 8219-0539
£33.74
29   UPPER BAFFLE PLATE, 410
Potterton part no. 8219-0017
£31.64
29   UPPER BAFFLE PLATE, 570
Potterton part no. 8219-0018
£42.54
30   LOWER BAFFLE PLATE, 412MM
Potterton part no. 8219-0019
£52.87
30   LOWER BAFFLE PLATE, 572MM
Potterton part no. 8219-0020
£73.78
31   BODY SCREWS PACKET
Potterton part no. 8219-7724

32   FASTENERS FOR BOILER DOOR
Potterton part no. 8219-8957
£15.84
33   NIPPLE GREASING PRODUCT
Potterton part no. 9430-5027
£21.94
34   TUBE SILICONE P520P420 & P320
Potterton part no. 9428-5095
£27.53
50   BRUSH FOR P SERIES
Potterton part no. 9750-5025

51   BRUSH HANDLE 1300MM
Potterton part no. 9750-5060
£28.65
51   BRUSH ROD 1000MM
Potterton part no. 9750-5076
£25.40
